MGV8 Gauge Valve

Name: MGV8 Gauge Valve
Brand: MANIK ENGINEERS
Price: 3186 INR
Availability: InStock

3186 INR/Piece

Get a Price/Quote

Product Details:

Features Bubble-tight shut-off, Stainless Steel body, High-pressure resistance
Installation Type Panel or Pipe Mounting
Output Mechanical
Protection Level Corrosion resistant
Connectivity Type Threaded (BSP/NPT)
Mounting Type Panel Mount, Pipe Mount
Usage & Applications Isolating and controlling fluid/gas flow in instrumentation lines
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

MGV8 Gauge Valve Price And Quantity

Price 3186 INR/Piece
Minimum Order Quantity 100 Piece

Body Material SS316 Stainless Steel
Max Working Pressure 6000 PSI
Sealing Type Metal to PTFE
Packing Type PTFE
Handle Type T Bar Handle
Surface Finish Polished
End Connection Screwed, Flanged options available
Seat Material PTFE
Bonnet Type Screwed
Stem Type Non-rotating tip

MGV8 Gauge Valve Product Specifications

Protection Level Corrosion resistant
Input Manual
Operating Temperature -20C to 200C
Features Bubble-tight shut-off, Stainless Steel body, High-pressure resistance
Application Fluid and gas pressure instrumentation systems
Installation Type Panel or Pipe Mounting
Output Mechanical
Usage & Applications Isolating and controlling fluid/gas flow in instrumentation lines
Dimension (L*W*H) Standard sizes as per model
Weight Approx. 0.5 - 1.2 kg
Measuring Range Up to 6000 PSI
Pressure Type High/Low Pressure
Accuracy High precision shut-off
Connectivity Type Threaded (BSP/NPT)
Working Temperature Up to 200C
Diameter 1/4 inch, 1/2 inch (Options Available)
Mounting Type Panel Mount, Pipe Mount
Product Type Gauge Valve

Body Material SS316 Stainless Steel
Max Working Pressure 6000 PSI
Sealing Type Metal to PTFE
Packing Type PTFE
Handle Type T Bar Handle
Surface Finish Polished
End Connection Screwed, Flanged options available
Seat Material PTFE
Bonnet Type Screwed
Stem Type Non-rotating tip

Product Description

Unlock unmatched control and reliability with the acclaimed MGV8 Gauge Valve, designed for formidable performance in demanding fluid and gas pressure instrumentation systems. Built with top-notch SS316 stainless steel and featuring a breathtaking polished surface, this valve delivers high precision shut-off and bubble-tight sealing thanks to its robust metal-to-PTFE mechanism. Get it now with versatile handle options, corrosion-resistant construction, and a max working pressure of 6000 PSI. Perfect for panel or pipe mounting, MGV8 is your go-to solution for high or low-pressure applications.

Application and Usage Versatility

The MGV8 Gauge Valve boasts an exceptional polished finish suitable for a range of industrial settings. Designed for isolating and controlling fluid or gas flow, it is ideal for instrumentation lines in laboratories, refineries, petrochemical plants, and general process industries. Its panel or pipe mounting capability ensures adaptability, while the bubble-tight shut-off and corrosion resistance make it reliable for both indoor and outdoor installations.

Supply Ability and Commercial Policies

With a dependable supply network across India, MGV8 Gauge Valve is always available at a competitive list price. Products are dispatched swiftly, and prompt handover ensures minimal downtime for your operations. Flexible payment terms accommodate various procurement processes, and our sample policy enables industry professionals to evaluate valve performance prior to bulk orders, guaranteeing satisfaction and trust in every transaction.

FAQ's of MGV8 Gauge Valve:

Q: How does the MGV8 Gauge Valve ensure high-precision shut-off?

A: The MGV8 Gauge Valve integrates a non-rotating tip stem and metal-to-PTFE sealing type, delivering bubble-tight shut-off and minimizing leakage, even under high-pressure conditions up to 6000 PSI.

Q: What mounting options are available for the MGV8 Gauge Valve?

A: This valve can be conveniently installed with either panel mounting or pipe mounting configurations, depending on the specific requirements of your instrumentation setup.

Q: Where is the MGV8 Gauge Valve typically used?

A: It is widely used in laboratories, petrochemical plants, and fluid/gas instrumentation systems due to its robust design and corrosion-resistant SS316 stainless steel body.

Q: What is the process for ordering and receiving the MGV8 Gauge Valve?

A: MGV8 Gauge Valves are available for export, supply, and wholesale. Once an order is placed, it is dispatched promptly, ensuring efficient delivery and handover aligned with our supply policies.

Q: What benefits does the PTFE seat and packing provide?

A: PTFE seat and packing offer enhanced chemical resistance, superior sealing, and durability, making the valve suitable for handling a variety of aggressive fluids and gases.

Q: How can I assess the MGV8 Gauge Valve before bulk purchase?

A: Our sample policy allows potential buyers to obtain a valve for evaluation, ensuring that the product meets their technical and operational requirements before placing a larger order.
