Product Description

The Liquid Level Controllers are available in 2 models.

Type LC 101 AI & 39FI

The Liquid Controller consists of a float chamber and an electronic controller. It can be used on all non corrosive liquids such as Ammonia, Toluene, Freon etc.
The electronic controller has a bar graph display module installed to continuously display the rising & falling of liquid level inside the float chamber. The level controller is used to control the liquid level in various refrigeration applications.

These level controllers can also be used as a protection against too high & too low liquid levels.
SPECIFICATIONS :

• Refrigerant R717 (NH3), R22, R502, R404a etc.

• Differential Adjustable between 10 to 40 mm.

• Max operating pressure for float housing 19 bar.

• Enclosure for float housing IP 65

• Amplifier / controller is available in IP 65 wall mounting

  enclosure or DIN 1/4 for panel mounting enclosure.

• Float Chamber and Amplifier are also available in flame

  proof enclosure.
