FS-100 E Flow Switch Price : 6086 INR/Piece Minimum Order Quantity : 1 Application : Water, Oil, General Liquids Flow Monitoring Diameter : 1 (25 mm) BSP Features : Sturdy Brass Body, Adjustable Set Point, Compatible with Hot or Cold Water Input : Mechanical Paddle Usage & Applications : HVAC, Pump Protection, Fire Protection, Water Treatment, Process Control Product Type : FS100 E Flow Switch Installation Type : Inline (Pipeline) Mounting Type : Pipe Mounted Operating Temperature : 10C to 60C Working Temperature : 10C to 60C Weight : Approx. 350 g Accuracy : 10% Pressure Type : Max 10 Bar (145 PSI) Dimension (L*W*H) : Approx. 95 x 38 x 100 mm Connectivity Type : Screw Terminal Protection Level : IP54 Measuring Range : 1~30 L/min (Depending on pipe size) Output : SPDT (Single Pole Double Throw) Switch Type : PaddleActuated Switch Current : 10A Max IP Rating : IP54 Sensor Type : Reed Switch/Paddle Type

MOSCV Oil Separator Control Valve Price : 50000 INR/Piece Minimum Order Quantity : 1 Application : Refrigeration and HVAC systems Diameter : 15 mm Features : High separation efficiency, robust construction, low maintenance Input : Pressure from compressor discharge line Usage & Applications : Oil separation in refrigeration compressor units Product Type : Oil Separator Control Valve Installation Type : Inline/Brazed Mounting Type : Horizontal/Vertical Operating Temperature : 40C to +120C Working Temperature : 40C to +120C Weight : 0.85 kg Accuracy : High accuracy separation efficiency Pressure Type : High Pressure Dimension (L*W*H) : 120 mm x 54 mm x 54 mm Connectivity Type : Mechanical connection Protection Level : Other, Corrosionresistant body Measuring Range : Up to 45 bar Output : Controlled refrigerant oil flow Switch Type : Manual/Automatic Current : 0.5A IP Rating : IP54 Sensor Type : Mechanical

High Pressure Stop Valves Type MHPSV Price : 5986 INR/Piece Minimum Order Quantity : 1 Application : Steam, Gas, Oil, Water Diameter : 15 mm to 50 mm Features : Robust construction, leakproof, suitable for highpressure fluids Input : Manual Usage & Applications : Industrial piping for isolation at high pressures Product Type : High Pressure Stop Valves Type MHPSV Installation Type : Flanged or Screwed Mounting Type : Horizontal / Vertical Operating Temperature : 20C to +80C Working Temperature : Up to 80C Weight : Depends on size and material Accuracy : High Sealing Accuracy Pressure Type : High Pressure Dimension (L*W*H) : Customized as per model Connectivity Type : Threaded / Flanged Protection Level : Other, Corrosion Resistant Measuring Range : Up to 600 bar Output : Flow Isolation Switch Type : Manual

MGV8 Gauge Valve Price : 3186 INR/Piece Minimum Order Quantity : 100 Application : Fluid and gas pressure instrumentation systems Diameter : 1/4 inch, 1/2 inch (Options Available) Features : Bubbletight shutoff, Stainless Steel body, Highpressure resistance Input : Manual Usage & Applications : Isolating and controlling fluid/gas flow in instrumentation lines Product Type : Gauge Valve Installation Type : Panel or Pipe Mounting Mounting Type : Panel Mount, Pipe Mount Operating Temperature : 20C to 200C Working Temperature : Up to 200C Weight : Approx. 0.5 1.2 kg Accuracy : High precision shutoff Pressure Type : High/Low Pressure Dimension (L*W*H) : Standard sizes as per model Connectivity Type : Threaded (BSP/NPT) Protection Level : Other, Corrosion resistant Measuring Range : Up to 6000 PSI Output : Mechanical
