Digital Temperature And Humidity Controller

Digital Temperature And Humidity Controller

Name: Digital Temperature And Humidity Controller
Brand: MANIK ENGINEERS
Price: 5886 INR
Availability: InStock

5886 INR

Get a Price/Quote

Product Details:

Phase Single
Switch Type Relay
Protection Level IP20
Mounting Type Panel Mount
Pole Type Single Pole
Sensor Type NTC Thermistor & Capacitive Humidity Sensor
Output Relay output
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Digital Temperature And Humidity Controller Price And Quantity

Minimum Order Quantity 1 Piece
Price 5886 INR

Operating Humidity 10%~90%RH (non-condensing)
Hysteresis Setting Available
Set Point Adjustability Yes (user programmable)
Display Resolution 0.1C / 1%RH
Storage Temperature -20C to 60C
Control Method On/Off Switch Control
Alarm Function Built-in audible and visual alarm
Relay Contact Capacity 10A/250VAC
Display Color Red/Green (depending on model)
Response Time <3 seconds
Enclosure Material ABS Plastic

Digital Temperature And Humidity Controller Product Specifications

Phase Single
Weight Approx. 130g
Switch Type Relay
Product Type Digital Temperature And Humidity Controller
Pressure Type Atmospheric
Protection Level IP20
Mounting Type Panel Mount
Pole Type Single Pole
Sensor Type NTC Thermistor & Capacitive Humidity Sensor
Output Relay output
Supply Voltage AC 220V/110V or DC 12V/24V
Input Sensor input (NTC thermistor, humidity sensor)
Working Temperature -10C to 60C
Dimension (L*W*H) Approx. 85mm x 75mm x 35mm
Current 10A Max
Features Wide measuring range, programmable control, digital display, over-temperature and humidity protection
Application Industrial, HVAC, Agriculture, Greenhouse
Diameter Standard panel size
IP Rating IP20
Frequency 50/60Hz
Accuracy 1C (Temperature), 5%RH (Humidity)
Usage & Applications Temperature and humidity controlling in industrial and agricultural environments
Connectivity Type Wired
Operating Temperature 0C to 50C
Display Digital LED/LCD
Installation Type Panel Mounted
Measuring Range Temperature: -40C to 120C, Humidity: 0%RH to 100%RH

Operating Humidity 10%~90%RH (non-condensing)
Hysteresis Setting Available
Set Point Adjustability Yes (user programmable)
Display Resolution 0.1C / 1%RH
Storage Temperature -20C to 60C
Control Method On/Off Switch Control
Alarm Function Built-in audible and visual alarm
Relay Contact Capacity 10A/250VAC
Display Color Red/Green (depending on model)
Response Time <3 seconds
Enclosure Material ABS Plastic

Digital Temperature And Humidity Controller Trade Information

Supply Ability 50 Piece Per Week
Delivery Time 1 Week
Main Export Market(s) Western Europe, Australia, North America, Eastern Europe, Middle East, Central America, South America, Asia, Africa
Main Domestic Market All India

Product Description

We offer computerized temperature and dampness controller which expels Moisture introduce noticeable all around. The dampness crushes the nature of the items put away or being fabricated. We offer this item which is made entirely according to European gauges and utilized for controlling dampness in secured regions. Ideal for an assortment of zones like homes, inns and workplaces, our Room Dehumidifiers are immaculate notwithstanding for Industrial regions where producing, preparing, bundling, and capacity is finished. Our Room Dehumidifiers offer appropriate dampness control, in this way keeping the arrangement of rust, protuberances in items and the development of microorganisms, molds, organism, buildup et cetera.

Versatile Environmental Monitoring

Engineered for broad applications, this digital controller excels in industrial, agricultural, and HVAC environments. Its advanced sensors including an NTC thermistor and capacitive humidity sensor enable accurate measurements, providing dependable control suited to critical processes. Whether you are automating greenhouses or optimizing factory conditions, the device delivers steady performance and adaptability across demanding settings.

Precise Control and User-Friendly Features

With user-programmable set points and available hysteresis adjustment, the controller allows tailored regulation for precise requirements. Rapid response time (under 3 seconds), a bright red or green digital display, and both audible and visual alarms enhance operation and safety. The system supports quick sensor input and is equipped to handle a maximum current of 10A, offering flexible utility and peace of mind.

FAQs of Digital Temperature And Humidity Controller:

Q: How can I program the set points for temperature and humidity on the controller?

A: You can conveniently adjust the set points using the controllers user-friendly interface. Access the programming mode, follow the display prompts, and input desired temperature or humidity levels within the measuring range (-40C to 120C for temperature; 0%RH to 100%RH for humidity). Consult the user manual for detailed steps specific to your model.

Q: What types of alarms does this controller feature, and how do they function?

A: This digital controller is equipped with both audible and visual alarms. When the monitored temperature or humidity exceeds your predefined set points, the system instantly triggers alarms, alerting you on-site for quick intervention. The alarms promptly indicate abnormal conditions, supporting rapid corrective measures.

Q: Where is the optimal installation location for this device?

A: The controller is designed for panel mounting and is best installed in environments requiring precise ambient management, such as greenhouses, industrial plants, or HVAC panels. Ensure it is mounted away from direct exposure to water or dust, in locations within the recommended operating temperature (0C to 50C) and humidity (10%~90%RH non-condensing) ranges.

Q: What are the benefits of the hysteresis setting on this controller?

A: The hysteresis setting lets you define allowable fluctuations around the set point, preventing frequent relay switching and reducing wear. This feature enhances control stability and prolongs the life of connected systems by minimizing unnecessary cycling.

Q: How responsive is the controller to changes in environmental conditions?

A: Thanks to its advanced sensors and optimized circuitry, the controller boasts a fast response timeless than three secondsallowing rapid adaptation to environmental fluctuations and ensuring reliable temperature and humidity regulation.

Q: What applications is this controller suitable for?

A: This device is ideal for usage in industrial operations, agricultural facilities, HVAC systems, and greenhouses. Its wide measuring range and programmable controls make it suitable for environments requiring stringent climate regulation, such as storage rooms, production floors, or commercial grow areas.

Q: What is the process for connecting sensors and managing outputs?

A: To connect sensors, attach the supplied NTC thermistor and capacitive humidity probe to the input terminals as per wiring instructions. The controller processes the data and, if thresholds are crossed, activates the on/off relay accordingly, triggering output devices like fans or dehumidifiers. Ensure power is off during wiring for safety.
